CEILING MOUNTED VENTILATION FAN-INTELLIGENT TYPE
Outline：
Classification：
Ventilation Fan
Product Description
Features
- The appearance design is beautiful and fashionable, suitable for integrated and traditional panel use.
- Ultra-thin body to achieve narrow space installation.
- Suitable for integrated or ordinary ceiling panels.
- When the product is turned on, it can run 24 hours without cutting off the power supply. The product automatically adjusts the air volume with the change of air quality in the place of use, so as to ensure the comfort of the place of use.
- Wireless control logic: Temperature I(<28℃) Ⅱ(28℃-30℃) Ⅲ(>30℃); Humidity I(<80%) Ⅱ(80%-85%) Ⅲ(>85%); VOC I(0) Ⅱ(1,2) Ⅲ(3)
PRODUCT DIMENSIONS
| Model | A | B | C | D | E | F | G | H | I | J | K | L |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ED-D100-G1-J156-F1 | 297 | 232 | 163 | 300 | 97 | 46 | 20 | 274 | 252 | 124 | 12.0 | 8.0 |
| ED-D150-G1-J366-F1 | 344 | 264 | 202 | 320 | 147 | 42 | 20 | 310 | 290 | 140 | 12.0 | 8.0 |
TECHNICAL PARAMETERS
| Model | Voltage (V) | Power (W) | Air Flow (m³/h) | Static Pressure (Pa) | Noise (dBA) | Pipeline Size (mm) |
|---|---|---|---|---|---|---|
| ED-D100-G1-J156-F1 | 220/110 | 4.3~6.9~12.5 | 90~120~156 | 33~75~155 | 30~35~41 | Ø100 |
| ED-D150-G1-J366-F1 | 220/110 | 6~11.2~27.3 | 192~258~366 | 42~100~242 | 32~39~45 | Ø150 |
Note
- 1. Data such as air volume, power and noise value are measured at a static pressure of 0Pa.
- 2. The noise value is the average sound power level of A-weight. The test method is to measure the noise value in the noise test room at a distance of 1.0m from the left, right and lower directions of the fan (the air outlet is connected with a 1m air duct), and then take the average value. This test method is based on the assumption that body noise is transmitted indoors.
