PRODUCTS CENTER
TURBOCHARGED INLINE FAN-MIXED FLOW FAN-INTELLIGENT
Outline：
Classification：
Ventilation Fan
Product Description
Features
- Turbocharged duct fan: more powerful suction, stronger wind, quieter sound.
- The turbocharged airfoil, turbine-type fan blades and draft coils combine with flow dynamics to make the exhaust air more powerful.
- Beautiful and fashionable appearance, small size, saves installation height.
- Innovative fixed bracket, convenient installation, easy maintenance.
- When the product is turned on, it can run 24 hours without cutting off the power supply. The product automatically adjusts the air volume with the change of air quality in the place of use, so as to ensure the comfort of the place of use.
- Wireless control logic: Temperature I(<28℃) Ⅱ(28℃-30℃) Ⅲ(>30℃); Humidity I(<80%) Ⅱ(80%-85%) Ⅲ(>85%); VOC I(0) Ⅱ(1,2) Ⅲ(3)
PRODUCT DIMENSIONS
| Model | A | B | C | D | E | F | G | H | I |
|---|---|---|---|---|---|---|---|---|---|
| ED-F100-G1-S198-F2 | 175 | 212.9 | 95.2 | 60 | 350 | 84.4 | 33.6 | Ø4.5 | Ø98 |
| ED-F150-G1-S450-F2 | 197 | 232.9 | 104.5 | 80 | 320 | 84.2 | 53.2 | Ø4.5 | Ø147 |
| ED-F200-G1-S630-F2 | 233 | 283.4 | 123 | 100 | 373 | 93.6 | 68 | Ø4.5 | Ø195 |
| EE-F200-G1-S900-F2 | 233 | 283.4 | 123 | 100 | 373 | 93.6 | 68 | Ø4.5 | Ø195 |
TECHNICAL PARAMETERS
| Model | Voltage (V) | Power (W) | Air Flow (m³/h) | Static Pressure (Pa) | Noise (dBA) | Pipeline Size (mm) |
|---|---|---|---|---|---|---|
| ED-F100-G1-S198-F2 | 220/110 | 8~14.3~23.7 | 130~160~198 | 92~156~229 | 28~33~37 | Ø100 |
| ED-F150-G1-S450-F2 | 220/110 | 14~28.5~44 | 280~360~450 | 136~238~317 | 29~35~39 | Ø150 |
| ED-F200-G1-S630-F2 | 220/110 | 36~54~65 | 480~560~630 | 160~230~280 | 35~39~40 | Ø200 |
| EE-F200-G1-S900-F2 | 220/110 | 95~125~145 | 720~800~900 | 385~476~545 | 46~48~49 | Ø200 |
Note
- 1. Data such as air volume, power and noise value are measured at a static pressure of 0Pa.
- 2. The noise value is the A-weighted average sound power level. The test method is to measure the noise value in the noise test room at a distance of 1.5m from the front, back and lower directions of the fan (the air inlet and air outlet of the fan are each connected with 1m air ducts), and then take the average value. This test method is based on the assumption that body noise is transmitted indoors.
