Product Description
★绝缘等级Insuation:Class B
★保护等级Type of protection:IP42
★工作模式 Mode of operation:S1
★安规认证Certification:CE
★温度范围Operation Temperature:-20--70℃
★材质Material:Pa66
★功能选择AvailableFeatures:·Tachilable Out put转速输出 ·Autorestart自动重启 ·Slow startup软启动 ·Pulse WIDTH Modulation脉宽调节 ·Control input控制输入0--10VDC
★ EMC:Interference emission acc.to EN 61000-6-3
★ Interference immunily acc.to EN 610oo-6-2
★ Product conforming to standard: EN 60950-1
SPECIFICATIONS
| 产品型号 Model |
轴承型式 Bearing System | 电压 Voltage V | 电压范围 Voltage Range | 电流 Current A | 功率 Power W | 转速 Speed RPM | 噪音 Noise DBA | 风量 Air Flow | 静压 Static Pressure | 重量 Weight G | ||
| M³/H | CFM | Pa | mmH₂O | |||||||||
| TE50002HB-A | Ball | 230VAC | 200--277 | 3.43 | 814.2 | 1400 | 78.05 | 7614 | 4481 | 252 | 25.7 | 6500 |
| TE50002HB-B | Ball | 230VAC | 200--277 | 3.43 | 814.2 | 1400 | 78.05 | 7614 | 4481 | 252 | 25.7 | 6500 |
